Precision Beyond Sight, Safety with Leikan
2 Years
| Ask Lasest Price | |
| Brand Name : | LeiKan |
| Model Number : | LKLQ-PRT2003 |
| Payment Terms : | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
The LKLQ-PRT2003 handheld drone defense system finds, blocks, and redirects drones. Its clear touchscreen shows live threats, making it ideal for protecting key sites and ensuring airspace safety.
1. Visit the factory and conduct on-site testing before purchasing
2. The product can be returned or replaced within 30 days if damaged under non‑human causes.
3. Multi channel after-sales service support: We offer a variety of service options, including telephone support, video conferencing, and on-site technical support (when eligible).
4. Our products have obtained CE, FCC and REACH certifications and comply with international standards.
5. We offer various modes of cargo transportation, including sea freight, land transport, multimodal transport, as well as express/parcel services via carriers such as DHL, FedEx, or postal networks. You may also appoint your preferred freight forwarder for shipment arrangements.
6. For all equipment, we conduct over ten comprehensive qualification tests prior to shipment, along with on-site simulation testing to ensure operational readiness.
7. Can provide testing reports for various types of products.
1. Integrated Design:Combines detection, jamming, and spoofing functions into a single compact device for easy deployment.
2. Full-Band Detection:Supports message parsing, digital video transmission detection, and analog video transmission detection, covering 600MHz–6GHz.
3. Real-Time Situational Awareness: Features a full-state high-definition touchscreen with high-resolution display for real-time threat labeling and clear visual feedback.
4. Fast Response and Long Battery Life: Signal intrusion time <10 seconds, battery life ≥10 hours (in detection mode), suitable for prolonged operations.
5. Customizable Functionality: Configurable parameters such as operating frequency bands and spoofing range to meet diverse security needs.
1. Detecting unit performance parameters
Detection Mode | Protocol Analysis / Digital Video Transmission Detection / Analog Video Transmission Detection |
Protocol Analysis: DJI O2/O3/O4 flight control protocol models, National Standard messages | |
Detectable Models | |
Digital Video Transmission Detection: Common consumer-grade drone models | |
Analog Video Transmission Detection: Analog video transmission models within 600MHz–6GHz | |
Detection Range | |
Protocol Analysis ≥ 1km | |
Digital Video Transmission ≥ 1km | |
Analog Video Transmission ≥ 1km | |
Detection Feedback | On-screen display and indicator warning |
Battery Life | ≥ 10 hours (in detection mode) |
2. Jamming Unit Performance Parameters
Jamming Mode | Fixed-frequency jamming, Programmable-frequency jamming |
Jamming Bands | Fixed-frequency: 2.4GHz, 5.2GHz, 5.8GHz |
Programmable-frequency: 100MHz–6GHz | |
Jamming Range | ≥ 1km (jamming-to-communication ratio > 3:1) |
Jamming Strategy | Automatic strike / Fixed-frequency strike |
Operating Mode | Navigation jamming / Navigation spoofing |
Frequency Bands | GPS L1 GLONASS G1 BDS B1 GALILEO E1 (customizable) |
Spoofing Range | ≥ 1km (customizable) |
Signal Intrusion Time | < 10 seconds |
Screen Specifications | 10.1" IPS Touchscreen, 1920×1200px, 700 cd/m² brightness |
Power Supply | Lithium battery, supports hot-swapping |
Charging Time | ≤ 2 hours |
Protection Rating | IP65 |
Operating Temperature | –20°C to +60°C |
Dimensions (L×W×H) | 410×360×211 ±5 mm |
Power Consumption | ≤ 150W |
Weight | ≤ 8 kg |
1. Multi-Technology Detection: Combines protocol parsing, digital/analog video transmission detection for improved target identification accuracy.
2. Precision Navigation Signal Control: Supports jamming and spoofing of multiple satellite navigation systems (GPS/GLONASS/BDS/GALILEO).
3. Efficient Human-Machine Interaction: Intuitive touchscreen interface with clear detection information display, easy to operate.
4. Strong Environmental Adaptability: Detection range ≥1 km in line-of-sight conditions, suitable for most security scenarios.
5. Modular Scalability: Customizable functions and system integration options to adapt to various security frameworks.
|
|
